HD10AVA
SD/HD Analog Composite or Component Video & 4-Channel Analog Audio to SD/HD-SDI with Embedded Audio
The HD10AVA is a miniature, high-quality, audio/video, HD/SD A/D converter. The HD10AVA automatically detects the video input format and embeds the audio inputs in the SDI/HD-SDI outputs. The HD10AVA is useful for adding an SDI/HD-SDI audio/video output to tape decks or any professional video equipment with analog outputs. The HD10AVA is especially useful for adding HD-SDI outputs to most HDV cameras or decks by using the component outputs of such devices. The HD10AVA uses a breakout cable for audio/video inputs and provides 3 SDI-HD-SDI outputs on BNCs.
Specifications
Formats| 1080i 50/59.94/60 Hz |
| 1080psf 23.98/24/25 Hz |
| 1035i 50/59.94/60 Hz |
| 720p 50/59.94/60 Hz |
Video Inputs
| HD component YPbPr, (SMPTE-274), BNC |
| SD component/composite/YC (S Video), BNC |
Audio Inputs
| 4-channel balanced, XLR |
Outputs
| SDI, HD-SDI, SMPTE-259/292/296, 3 x BNC |
Video A/D
| 12 bits |
Audio A/D
| 24 bits, 48 KHz |
Audio Levels
| +10dBu, +12dBu, +18dBu, +24dBu, full-scale digital |
User Controls
| External dipswitch |
| Component/composite (SD) |
| Composite/YC (SD) |
| Pedestal present (on/off) (SD) |
| Audio input level |
Power
| +5 to 18V DC, 5 Watts, Power Supply Required (sold separately) |
Size
| 5.8" x 3.1" x 1" (147 x 79 x 25mm) |
HD10AVAClick to view larger |
HD10AVA Cable(included) |
 |
 |
