openGear 4K/UltraHD/2K/HD/SD HDMI 2.0 to 3G-SDI Conversion

$835 US MSRP*

* Pricing is for US only. International pricing will vary.

OG-HA5-4K

Overview

Tech Specs

Downloads

openGear HDMI

Overview

Featuring four 3G-SDI outputs, the openGear compatible OG-HA5-4K enables high quality conversion of HDMI 2.0 video from DSLRs, mirrorless cameras, action cameras, or prosumer 4K video cameras to 4K/UltraHD 3G-SDI for use in professional workflows. OG-HA5-4K is also capable of displaying HDR infoframe data coming in over HDMI when used with DashBoard software.

Designed for use in high density openGear 2RU frames including AJA’s OG-X-FR frame, DashBoard Software support on Windows®, macOS® and Linux® offers remote control and monitoring of the openGear architecture and provides convenient and industry-standard configuration, monitoring and control options over a PC or local network.

Features

  • openGear compatible card
  • Convert HDMI 2.0 to Quad-3G, 4K/UltraHD 60 fps at 4:4:4, 4:2:2, and 4:2:0
  • Supports Two Sample Interleave (2SI) and Square Division (Quadrant) output pixel mapping
  • EDID Emulation
  • Displays HDR Infoframe data coming in over HDMI in accordance with HDMI v2.0b/CTA-861-G
  • HDR Metadata VPID Pass-through and optional override
  • Simple Frame Rate Conversion (FRC)
  • Embedded audio support 8-channel 24-bit
  • Embedded audio pass-through of AC-3 (Dolby Digital Plus) and E-AC-3 compressed audio, including DD+ Atmos (aka DD+ JOC)
  • Remote Ethernet configuration through Ross DashBoard software
  • Power: 10 watts
  • Hot-swappable
  • Rear I/O card included
  • Two slots required for each card
  • Compatible with OG-X-FR, OG-3-FR, and DFR-8321 openGear frames
  • Five year warranty

Connectivity

An increasing number of 4K products utilize an HDMI output connection, which allows a full 4K signal to be passed over a single cable. Typical professional 4K workflows use four SDI cables to carry the full resolution image, making it difficult to incorporate these newer devices. OG-HA5-4K is an easy-to-use converter that bridges the gap between these two worlds for seamless integration.

HDR

HDR or High Dynamic Range,  provides the ability to display a wider and richer range of colors, much brighter whites, and much deeper, darker blacks than standard signals allow. This gives your imagery a more ‘dynamic’ look and allows for natural true to life colors to be communicated to your audience.

OG-HA5-4K  provides support for analyzing HDR infoframe data coming in over HDMI when used with DashBoard software.

Explore more of our HDR Solutions here:

HDR Solutions

4K and UltraHD

OG-HA5-4K supports conversion of full resolution 4K (4096x2160) as well as UltraHD (3840x2160) from HDMI to 3G-SDI at frame rates up to 50/60 fps, providing a great solution for cinematic 4K productions as well as UltraHD projects.

HD Support

Not every job is a 4K job. When you're not working in 4K, OG-HA5-4K can still be a useful tool for converting HD-HDMI to HD-SDI. OG-HA5-4K will automatically sense an incoming HD resolution HDMI signal and convert this to a single 3G-SDI output, much like AJA's HA5-Plus Mini-Converter.

Audio

Up to 2-channels of embedded audio in the incoming HDMI signal are carried through seamlessly into the SDI output, ensuring your audio is always in sync and carried flawlessly along with the SDI signal for use anywhere in your workflow.

openGear Compatibility

The openGear standard ensures that AJA cards will be compatible with other openGear products from certified openGear partners. With a growing list of products, openGear is the future of rackframe products.

DashBoard Software

Ross DashBoard software offers quick and convenient configuration and control of openGear cards on macOS, Windows, and Linux.

AJA Mini-Matrix

Information on the complete line of AJA openGear frames and cards is now available in the Mini-Matrix mobile app on iOS. AJA products are extensive and this app helps you find the right converter for any situation, wherever you are.

Individual products have links back to the main AJA website for more details and you can email product information directly from the app. The free AJA Mini-Matrix app for iPad® and iPhone® is available now in the Apple iTunes® Store.

Download from the Apple App Store

Launch Browser Version for Android

Industry Leading Support

AJA’s technical support is recognized as among the best in the industry and is available to all AJA customers. If you need assistance with any aspect of your openGear installation, configuration, operation or encounter any technical issue, AJA Support will work with you to get up and running.

openGear products are covered by a generous five year warranty.  Please see the individual Product’s Manual for additional specifics around warranty conditions for the product itself.

Tech Specs

Print Tech Specs

Video Formats

  • (4K) 4096 x 2160p
  • (UltraHD) 3840 x 2160p
  • (2K) 2048 x 1080p
  • (HD) 1920 x 1080p
  • (HD) 1920 x 1080i
  • (HD) 1280 x 720p
  • (SD) 720 x 576p
  • (SD) 720 x 576i
  • (SD) 720 x 480p
  • (SD) 720 x 480i



Note: Raster and Frame Rate Dependent, please see OG-HA5-4K Video Formats in Documents and Manual.

Video Input Digital

  • 1x HDMI Type A connector, HDMI v2.0b
    • HDR Infoframe decoder as defined in CTA-861.3 and HDMI v2.0b
    • HDR VPID generation with pass-through or override for Colorimetry and Transfer Characteristic
    • YCbCr 4:2:2/4:4:4/4:2:0
    • RGB 4:4:4, SMPTE or Full level
    • 8, 10, or 12-bit (HFR 4K/UltraHD 4:4:4 limited to 8-bit)
    • (4K) 4096 x 2160p 23.98, 24, 25, 29.97, 30, 47.95, 48, 50, 59.94, 60
    • (UltraHD) 3840 x 2160p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
    • (2K) 2048 x 1080p 23.98, 24, 25, 29.97, 30, 47.95, 48, 50, 59.94, 60
    • (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
    • (HD) 1920 x 1080i 50, 59.94, 60
    • (HD) 1280 x 720p 50, 59.94, 60
    • (SD) 720 x 576p 50
    • (SD) 720 x 576i 50
    • (SD) 720 x 480p 59.94
    • (SD) 720 x 480i 59.94

HDCP Decryption

  • Not supported. By definition, SDI outputs are unencrypted.

Video Output Digital

  • 4x 3G-SDI BNC, SMPTE-259/292/424
    • YCbCr 4:2:2/4:4:4
    • RGB 4:4:4, SMPTE or Full level
    • 10-bit
    • Two Sample Interleave (2SI) or Square Division (Quadrant) pixel mapping
  • 4x 3 Gb SDI (Level A or B Dual Link)
    • (4K) 4096 x 2160p 23.98, 24, 25, 29.97, 30, 47.95, 48, 50, 59.94, 60
    • (4K) 4096 x 2160PsF* 23.98, 24, 25, 29.97, 30
    • (UltraHD) 3840 x 2160p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
    • (Ultra HD) 3840 x 2160PsF* 23.98, 24, 25, 29.97, 30
  • 4x 1.5 Gb SDI
    • (4K) 4096 x 2160p 23.98, 24, 25, 29.97, 30
    • (4K) 4096 x 2160PsF 23.98, 24, 25, 29.97, 30
    • (UltraHD) 3840 x 2160p 23.98, 24, 25, 29.97, 30
    • (UltraHD) 3840 x 2160PsF 23.98, 24, 25, 29.97, 30
  • 2x 3 Gb SDI (Level B Dual Stream)
    • (4K) 4096 x 2160p 23.98, 24, 25, 29.97, 30
    • (4K) 4096 x 2160PsF 23.98, 24, 25, 29.97, 30
    • (UltraHD) 3840 x 2160p 23.98, 24, 25, 29.97, 30
    • (UltraHD) 3840 x 2160PsF 23.98, 24, 25, 29.97, 30
  • 2x 1.5 Gb SDI (Dual Link HD-SDI), SMPTE-372
    • (HD) 1920 x 1080p 50, 59.94, 60
  • 1x 3 Gb SDI (Level A or B Dual Link)
    • (2K) 2048 x 1080p 23.98, 24, 25, 29.97, 30, 47.95, 48, 50, 59.94, 60
    • (2K) 2048 x 1080PsF 23.98, 24, 25, 29.97, 30
    • (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
    • (HD) 1920 x 1080PsF 23.98, 24, 25, 29.97, 30
    • (HD) 1920 x 1080i 50, 59.94, 60
    • (HD) 1280 x 720p** 50, 59.94, 60
  • 1x 1.5 Gb SDI
    • (2K) 2048 x 1080p 23.98, 24, 25, 29.97, 30
    • (2K) 2048 x 1080PsF 23.98, 24, 25, 29.97, 30
    • (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30
    • (HD) 1920 x 1080PsF 23.98, 24, 25, 29.97, 30
    • (HD) 1920 x 1080i 50, 59.94, 60
    • (HD) 1280 x 720p 50, 59.94, 60
  • 1x 270 Mb SDI
    • (SD) 625i 50
    • (SD) 525i 59.94



*PsF is Level B Dual Link
**1280 x 720p is Level A Only

Audio Pass-Through Formats

  • PCM
  • Dolby Digital (AC-3)
  • Dolby Digital Plus (E-AC-3), including Atmos Immersive Sound (JOC)

Audio Input Digital

  • HDMI embedded audio, 24-bit, 8-channel

Audio Output Digital

  • SDI embedded audio, 24-bit, 8-channel

User Interface

  • openGear DashBoard network control software via Windows, macOS, or Linux

Size (w x d x h)

  • openGear standard form factor, front slot and rear card
  • Two slots required for each card

Weight

  • 0.5 lb (0.3 kg)

Power

  • openGear frame compatible, 10.0 watts max per card

Environment

  • Safe Operating Temperature: 0 to 40 C (32 to 104 F)
  • Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)
  • Operating Relative Humidity: 10-90% noncondensing
  • Operating Altitude: <3,000 meters (<10,000 feet)
