openGear 1x9 3G-SDI Reclocking DA

$625 US MSRP*

* Pricing is for US only. International pricing will vary.

Overview

The OG-3GDA-1x9 is a state of the art, openGear compatible, 3G-SDI distribution amplifier. The incoming 3G-SDI signal is reclocked and distributed to each of the nine 3G-SDI outputs, allowing the same signal to be sent to multiple destinations simultaneously.

Designed for use in high density openGear 2RU frames including AJA’s OG-X-FR frame, new DashBoard software support on Windows, macOS and Linux offers remote control and monitoring of the openGear architecture and provides convenient and industry standard configuration, monitoring and control options over a PC or local network.

Features

  • Video Formats: 150 Mbps - 3 Gbps, format agnostic
  • Input: 1x 3G-SDI BNC
  • Outputs: 9x 3G-SDI BNC
  • Support for HDR – High Dynamic Range video
  • Monitor via openGear DashBoard
  • Passes embedded audio, all ancillary data including closed caption and time code
  • Input Present and Input SMPTE Lock LEDs
  • Automatic input equalization and output reclocking
  • 270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.966 Gbps, 2.970 Gbps - Auto Select
  • Power: 2.5 watts max per card
  • Hot swappable
  • Compatible with OG-X-FR, OG-3-FR and DFR-8321 openGear frames
  • Five year warranty

Connectivity

The 3G-SDI input is automatically equalized and the outputs are automatically reclocked with best in class input jitter tolerance. SDI rates of 270Mb, 1.5Gb, and 3Gb are supported. One SDI input and nine SDI outputs are provided. A 10x BNC rear openGear connector module is included.

openGear Compatibility

The openGear standard ensures that AJA cards will be compatible with other openGear products from certified openGear partners. With a growing list of products, openGear is the future of rackframe products.

Flexible I/O

The modular rear panel allows custom I/O connections per card (included with individual cards).

Failsafe

The optional redundant power supply provides a secondary power source in the event of a primary power failure.

Ethernet Access

A standard Ethernet connection allows the frame to be accessed via the Ross Dashboard application for overall frame communication. Optional per-card Ethernet access can be installed in the frame for advanced communication with compatible openGear cards.

More Info

DashBoard Software

Ross DashBoard software offers quick and convenient configuration and control of openGear cards on macOS, Windows, and Linux.

AJA Mini-Matrix

Information on the complete line of AJA openGear frames and cards is now available in the Mini-Matrix. AJA products are extensive and this resource helps you find the right converter for any situation, wherever you are.

Individual products have links back to the main AJA website for more details.

Launch Mini-Matrix

Industry Leading Support

AJA’s technical support is recognized as among the best in the industry and is available to all AJA customers. If you need assistance with any aspect of your openGear installation, configuration, operation or encounter any technical issue, AJA Support will work with you to get up and running.

openGear products are covered by a generous five year warranty.  Please see the individual Product’s Manual for additional specifics around warranty conditions for the product itself.


Tech Specs


Video Formats

  • 150 Mbps - 3 Gbps, format agnostic

Video Input Digital

  • 1x 3G-SDI BNC, SMPTE-259/292/424

Video Output Digital

  • 9x 3G-SDI BNC, SMPTE-259/292/424
    • 5x outputs noninverting

Cable Equalization

(Belden 1694A coax)

  • 270 Mbps, 350m
  • 1.5 Gbps, 200m
  • 3 Gbps, 120m

Reclocking

  • 270 Mbps, 1.483 Gbps, 1.485 Gbps, 2.966 Gbps, 2.970 Gbps - Auto Select
  • All other rates are passed through and not reclocked

User Controls

  • openGear DashBoard network control software via Windows, macOS or Linux

Size (w x d x h)

  • openGear standard form factor, front slot and rear card
  • Two slots required for each card

Weight

  • 0.5 lb (0.3 kg)

Power

  • openGear frame compatible, 2.5 watts max per card

Environment

  • Safe Operating Temperature Range: 0C to 40C (32F to 104F)
  • Safe Storage Temperature Range (power OFF):-40C to 60C (-40F to 140F)
  • Operating Relative Humidity :10-90% noncondensing
  • Operating Altitude: <3,000m (<10,000ft)
