• Compact HDBaseT Block Camera
• UltraHD up to 29.97p or high frame rate HD support up to 60p
• Sony back illuminated 1/2.3 type 8.9 megapixel CMOS sensor
• Video, audio, control, and power over standard Cat 5e/6 cable
• Three year warranty

Software Features:

• Control and configure software for Rovocam
• When RovoCam is in UltraHD Mode, RovoControl’s unique ePTZ feature allows the user to select a 1080p HD ROI (Region of Interest) frame from the UltraHD raster for 1080p 50 or 1080p 59.94 output with full Pan, Tilt and Zoom capabilities
• Exposure control for simple camera control in the GUI
• Preset command and control with global, camera and ePTZ
• Import/Export of settings for sharing setups and configurations
• High DPI UI mode for GUI on high rez displays
• Crosshair selector for refined Spot AE and Spot Focus control
• Zoom control

RovoCam’s marriage of lens to delivery begins with superior Sony optics, complete with built-in 12x optical zoom and up to 20x zoom with Sony Super Resolution Zoom and autofocus or manual focus capabilities; all easily controlled remotely via Sony's VISCA protocol.

RovoCam is built around Sony’s 4K (Sony FCB-ER8300) camera module featuring a back illuminated CMOS sensor and Sony image processing for excellent performance.

What sets RovoCam apart from other cameras in its category, is an integrated HDBaseT interface supporting uncompressed video, power, stereo audio and RS-232 control over a single Cat 5e/6 cable running at lengths of up to 100 meters.

Delivering this much functionality and power with single cable connectivity dramatically simplifies installation, camera setup and footprint requirements.

Control and display RovoCam’s gorgeous UltraHD/HD imagery remotely with RovoRX-SDI and RovoControl.

RovoRX-SDI is a companion UltraHD/HD HDBaseT Mini-Converter receiver for RovoCam, with additional support for other higher frame rate HDBaseT workflows, with four integrated 6G/3G-SDI outputs and HDMI video and audio outputs for UltraHD and HD workflows.

Receive the RovoCam’s video and audio up to 100m away from the camera, and output to 6G/3G-SDI monitors, routers and recorders and HDMI TVs and devices simultaneously.

The HDBaseT connector on RovoRx-SDI supports camera uncompressed video, audio, power, and control, all over a single Cat 5e/6 cable, greatly simplifying cabling and systems integration.

RovoRx-SDI uniquely offers a DA Mode for signal distribution from an HDBaseT source, greatly expanding HDBaseT delivery options.

RovoRx-SDI connectivity includes:

• 4x 6G/3G-SDI outputs
• 1x HDMI UltraHD/HD output
• DA Mode for distributing multiple SDI signals from an HDBaseT source
• 1x RCA Stereo audio output
• 1x USB
• 1x RS-232 Bi-directional
• 1x HDBaseT connector (RJ-45) allowing for camera interaction, power, and control, all over one Cat 5e/6 cable.
• 5 year warranty
