Reliable and Affordable 10-bit Quality

PCIe 4x Card for 8/10-bit Uncompressed Digital SD, HD I/O

Ensure you are getting the highest quality signal in and out of your application with AJA's Corvid card. Corvid is the proven platform for digital uncompressed video and audio I/O, with support for SD and HD as well as 16-Channels of embedded 24-bit audio. Available in a standard sized PCIe card or "Low Profile" for when space is of the essence, Corvid uses AJA's common API which is supported across multiple operating systems.


  • 8/10-bit Uncompressed SD/HD PCIe I/O Card
  • PCI Express 4-lane
  • Available in PCIe form factor (Corvid) or PCIe Low Profile form factor (Corvid LP)
  • SDI or HD-SDI Input, SDI/HD-SDI Output
  • 16-Ch SDI Embedded Audio I/O, 24-bit 48 kHz
  • HD/SD Genlock, Reference Video or LTC Input (selectable)
  • Three year warranty

Powerful Platforms for
Development Partners

AJA's Developer Program allows partner companies to incorporate AJA products into their systems. By utilizing existing, proven video I/O devices, Developer Partners leverage AJA's expertise to develop and support these technologies, saving money and getting their integrated products to market more quickly.

Developer Sign Up

Industry-Leading Support

AJA’s technical support is recognized as among the best in the industry and is available to all AJA customers. If you need assistance with any aspect of your Corvid installation, configuration, operation or encounter any technical issue,  AJA Support will work with you to get up and running.

Corvid products are covered by a generous three year warranty. Please see the individual Product’s Manual for additional specifics around warranty conditions for the product itself.

Tech Specs

Video Formats

  • (HD) 1080i 50, 59.94, 60
  • (HD) 1080p 23.98, 24, 25, 29.97, 30
  • (HD) 1080PsF 23.98, 24, 25, 29.97
  • (HD) 720p 50, 59.94, 60
  • (SD) 625i 50
  • (SD) 525i 59.94

Video Input Digital

  • HD-SDI/SDI, SMPTE-259/292/296

Video Output Digital

  • HD-SDI/SDI, SMPTE-259/292/296

Audio Input Digital

  • 16-Channel 24-bit SDI embedded, 48 kHz synchronous

Audio Output Digital

  • 16-Channel 24-bit SDI embedded, 48 kHz synchronous


  • Independent LTC In/Out

Machine Code

  • Independent RS-422


  • Analog Color Black or HD Tri-Level sync

Size (w x d x h)

  • 0.55" x 6.61" x 2.16" (13.97 x 167.90 x 54.87 mm)


  • 0.7 lbs (0.4 kg)


  • Safe Operating Temperature: 0 to 40 C (32 to 104 F)
  • Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)
  • Operating Relative Humidity: 10-90% noncondensing
  • Operating Altitude: <3,000 meters (<10,000 feet)
