February 3, 2022

Grass Valley, CA (February 3, 2022) – AJA Video Systems has unveiled Io X3, a Thunderbolt™ 3-connected professional video and audio I/O device that offers HDR or SDR 2K/HD capture and output via 3G-SDI and HDMI. Compact, rugged, and portable, Io X3 streamlines high-quality HDR I/O up to 2K/HD 60p on compatible Thunderbolt™ 3-equipped Mac or PC hosts running professional video and audio applications.

Whether working remotely, on-set, or in a studio, Io X3 provides a powerful mobile solution for single-, dual-, and multi-channel SDI workflows, offering pristine 2K/HD/SD I/O with HDR directly from any modern laptop or computer. Lightning fast, flexible, and whisper-quiet, Io X3 is an ideal capture and output device for a range of production environments, including high-end color grading, audio mixing, on-set monitoring, or playback, and remote editorial and VFX. With four independent inputs for workflows with OBS and Wirecast, together with simultaneous MultiView monitoring for each source, Io X3 is also a perfect fit for streaming workflows.

Io X3 features eight switchable analog audio ports, allowing users to shift between eight channels in or out, or split connectivity between four inputs and four outputs, in addition to a 3.5 analog audio connection to plug in headphones directly. Up to 16-channel audio is included on each SDI port, and 8-channels on HDMI. Compact and rackmountable, Io X3 devices can easily be placed side by side in a rack for studio, mobile truck, or video assist needs, allowing users to benefit from up to eight channels of up to 2K/HD/SD I/O in a 1RU.

Io X3 feature highlights include:

  • Dual Thunderbolt™ 3 USB-C ports connect with modern Mac or PC laptops and desktop workstations and support daisy chain functionality
  • HDR support across SDI and HDMI ports
  • Four 3G-SDI bi-directional connections support single-, dual-, or multi-link workflows up to 2K/HD p60 YCbCr 10-bit or p30 RGB 12-bit
  • HDMI 1.4b I/O up to 2K/HD p60 YCbCr 10-bit or p30 RGB 12-bit I/O; HDR via 2.0 spec implementation
  • MultiViewer functionality for displaying up to four inputs for streaming workflows on a single HDMI reference monitor
  • The latest macOS Monterey and Windows 11 support and compatibility across both Apple M1 chip or Intel based systems
  • Optional rackmount kit for efficient rack mounting of two devices side by side, enabling up to eight channels of HD I/O in 1RU
  • Eight-channel analog audio I/O via DB25 connection
  • Analog audio ports are switchable between input and output, enabling users to swap between eight channels in or out, or split connectivity between four inputs and four outputs
  • Up to 16-channels of embedded audio on each SDI port, and up to 8-channels on HDMI
  • 3.5mm stereo analog audio connection for headphones
  • Dedicated reference, TLC input, and LTC output connections
  • RS-422 control port for tape-based workflows
  • Runs quiet for critical monitoring environments where silence is required
  • Includes proven AJA drivers and software plug-ins, with support for Apple Final Cut Pro, Adobe Creative Cloud, Avid Media Composer, Telestream Wirecast, OBS, and many others
  • Three-year AJA warranty and industry-leading technical support

"Today’s production environments demand increased content volume with fast turnaround, and the predominance of HD-centric workflows require flexible tools to support timely delivery of that material,” shared Nick Rashby, President, AJA Video Systems. “Io X3 simplifies complexities of video and audio workflows by providing teams with an affordable and high-quality solution for Thunderbolt™ 3-connected I/O on SDI and HDMI or multichannel I/O over SDI, helping video professionals at home, on site or in studio work more efficiently and with greater ease.”

Pricing and Availability
Io X3 is now available for $1,599 US MSRP through AJA’s worldwide reseller network. For more information, visit: /products/io-x3.

About AJA Video Systems, Inc.
Since 1993, AJA Video has been a leading manufacturer of video interface technologies, converters, digital video recording solutions and professional cameras, bringing high-quality, cost-effective products to the professional, broadcast and post-production markets. AJA products are designed and manufactured at our facilities in Grass Valley, California, and sold through an extensive sales channel of resellers and systems integrators around the world. For further information, please see our website at www.aja.com.

Workflows

AJA Video Systems Io X3 Multi-Channel 2K/HD/SD Video I/O over Thunderbolt™ 3Use Case: NLE Workflow for Io X3

Io X3 offers broad support for all major NLE applications, including Apple Final Cut Pro, Avid Media Composer and Adobe Premiere with a host of practical and easy to use features, shown in this NLE workflow diagram.

The Io X3 sits at the center of the NLE workflow, connected directly to the host laptop via super fast Thunderbolt 3. The NLE software is running on the host laptop, with the output of the time line being shown via both the HDMI port and the 3G-SDI port simultaneously, with support for HDR and SDR monitoring.

Read More



Use Case: OBS Workflow for Io X3Use Case: OBS Workflow for Io X3

Io X3 is directly compatible with OBS Studio, offering a comprehensive toolkit for mixing live video and taking the program content out to streaming destinations.

Io X3 again sits at the center of the workflow pictured opposite, providing the necessary video I/O for a 4 camera source program. Via Io X3's multi-channel support, the 4 HD cameras are connected directly to the 3G-SDI ports of the Io X3 which is connected via Thunderbolt 3 to the host PC or laptop.


Read More
